| Product Attribute | Attribute Value |
|---|---|
| Part Number | A2P75S12M3 |
| Manufacturer | STMicroelectronics |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 75A |
| Supplier Device Package | ACEPACK™ 2 |
| Series | - |
| Power - Max | 454.5 W |
| Package / Case | Module |
| Package | Tray |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| NTC Thermistor | Yes |
| Mounting Type | Chassis Mount |
| Input Capacitance (Cies) @ Vce | 4.7 nF @ 25 V |
| Input | Standard |
| IGBT Type | Trench Field Stop |
| Current - Collector Cutoff (Max) | 100 µA |
| Current - Collector (Ic) (Max) | 75 A |
| Configuration | Three Phase Inverter |
| Base Product Number | A2P75 |
